Key Features / Benefits
-
High Torque & Heavy-Duty Capacity – 126NM torque, supports gates up to 3.5m wide and 350kg per leaf.
-
Robust Gear Transmission – Hardened gear reducer for durability, smooth motion, and long service life.
-
Adaptive Drive Control – PID algorithm ensures precise speed and torque control.
-
All-Weather Performance – Operates reliably from -35°C to +85°C, suitable for extreme climates.
-
Safety Protection – Anti-pinch and anti-collision design, secure for users and equipment.
-
Smart Control Options – 433MHz wireless remote, optional APP/mobile control, and multiple input modes.
-
Easy Installation & Maintenance – Simplified structure, reinforced base, and modular design.
-
OEM & Distributor Friendly – Customization available, designed for bulk projects.
Specifications
| Item | Value |
|---|---|
| Motor Type | Brushless DC motor |
| Motor Power | 180W (optional 240W) |
| Torque | 126 NM |
| Gate Capacity | ≤ 350kg / leaf, ≤ 3.5m width |
| Gearbox | 20Cr hardened gear, high precision |
| Voltage | 24V DC (wide range 18–30V) |
| Frequency | 433 MHz (remote range ≤ 100m) |
| Working Temp. | -35°C ~ +85°C |
| Dimensions | 218 × 180 × 122 mm |
| Mounting Arm | 302 × 528 mm |
Applications
-
Heavy villa gates
-
Industrial facilities and factory entrances
-
Large commercial buildings and offices
-
High-security access points
Compliance & Certificates
-
UL (for U.S. market, optional)
-
FCC (for wireless modules)
-
CE & RoHS (for EU market)
-
ISO9001 Quality Management Certification
-
National High-Tech Enterprise Certification
Call to Action
👉 Contact us today for datasheets, bulk pricing, or OEM customization of the HZ03 heavy-duty series.
