Key Features / Benefits
-
Adaptive Drive Algorithm – Automatically adjusts to gate weight, no manual tuning required.
-
Reinforced 20Cr Gear Reducer – High strength, precision gears, longer lifespan.
-
One-Touch Safety Mode – Provides anti-pinch protection, ensuring user safety.
-
Guest Mode – Manual assist function for easy guest entry.
-
Heavy-Duty Mounting Base – 6mm reinforced steel plate, stable and anti-loosening.
-
Smooth Sliding Rail – Aviation-grade aluminum alloy + anodized finish for reliable performance.
-
Smart Controller & Remote – Simple setup, one-key operation.
-
All-Weather Durability – Reliable performance from -35°C to +85°C.
Specifications
| Item | Value |
|---|---|
| Motor Type | Brushless DC motor |
| Power | 60W |
| Speed | 1800 RPM |
| Torque | 60 NM |
| Voltage | 24V DC |
| Power Supply | 180W |
| Remote Frequency | 433 MHz |
| Working Temp. | -35°C ~ +85°C |
| Gate Weight | ≤ 180kg / leaf |
| Gate Width | ≤ 1.5m / leaf |
| Dimensions | 405 × 86 × 80 mm |
| Drive Arm Length | 330 mm |
| Slave Arm Length | Adjustable 360–410 mm |
| Sliding Rail | 485 mm |
| Housing Material | Cold-rolled steel + powder coating |
Applications
-
Residential gates and villas
-
Small commercial entrances
-
Office buildings and glass doors
-
Light-duty industrial access points
Compliance & Certificates
-
UL (for U.S. market, optional)
-
FCC (for wireless modules)
-
CE & RoHS (for EU market)
-
ISO9001 Quality Management Certification
Call to Action
👉 Contact us today for datasheets, distributor pricing, or OEM customization.
