Key Features / Benefits
-
Adaptive Drive Algorithm – Automatically adjusts to gate load, reducing installation time and ensuring smooth operation.
-
Multiple Models for Different Loads – From 60 NM up to 126 NM torque, suitable for a wide range of gate weights.
-
Heavy-Duty Construction – Reinforced steel mounting base and aviation-grade aluminum rail for stability and durability.
-
One-Touch Safety Mode – Anti-pinch and anti-collision design for safe operation.
-
Guest Mode – Manual assist opening for convenient guest entry.
-
Smart Controller & Multi-Function Remote – Easy configuration, one-key setup.
-
All-Weather Reliability – Operates from -35°C to +85°C, suitable for diverse climates.
-
OEM & Distributor Friendly – Flexible customization and bulk supply.
Specifications (Model Comparison)
| Model | Motor Power | Torque | Gate Weight Capacity | Dimensions (mm) | Voltage | Frequency | Working Temp. |
|---|---|---|---|---|---|---|---|
| HZ02-60 | 40W | 45 NM | Up to 150kg | 603×86×80 | 24V DC | 433 MHz | -35°C ~ +85°C |
| HZ02-80 | 60W | 60 NM | Up to 170kg | 602×86×80 | 24V DC | 433 MHz | -35°C ~ +85°C |
| HZ02-90 | 80W | 126 NM | Up to 350kg | 622×86×80 | 24V DC | 433 MHz | -35°C ~ +85°C |
Applications
-
Residential gates and villas
-
Commercial entrances and office buildings
-
Light industrial facilities
-
Hospitals, schools, and public institutions
Compliance & Certificates
-
UL (for U.S. market, optional)
-
FCC (for wireless modules)
-
CE & RoHS (for EU market)
-
ISO9001 Quality Management System
-
National High-Tech Enterprise Certification
Call to Action
👉 Contact us today for datasheets, distributor pricing, or OEM customization of the HZ02 series.
