Key Features / Benefits
-
Powerful & Flexible – Three models to fit different gate weights (light, medium, heavy-duty).
-
High Torque Output – From 40Nm to 126Nm, providing stable force for smooth opening.
-
Durable & Reliable – Built with hardened steel gears (20Cr+ carburized), ensuring long service life.
-
All-Weather Performance – Operates reliably in extreme temperatures (-35°C ~ +85°C).
-
Silent & Smooth Operation – Optimized motor and transmission reduce noise.
-
Enhanced Safety – Overload protection, anti-collision design, and stable closing.
-
Smart Control – Remote control (433 MHz), optional APP/WiFi integration.
-
Wide Applications – Suitable for residential gates, villa courtyards, commercial entrances, banks, and institutions.
Technical Specifications (by Model)
| Model | Torque Output | Rated Power | Gate Weight Capacity | Voltage | Speed | Dimensions |
|---|---|---|---|---|---|---|
| SafeTS-60 | 40 Nm | 40W | up to 100 kg/leaf | 24V DC | 1800 RPM | 165 × 65 × 80 mm |
| SafeTS-80 | 60 Nm | 60W | up to 170 kg/leaf | 24V DC | 1800 RPM | 205 × 85 × 95 mm |
| SafeTS-90 | 126 Nm | 80W | up to 350 kg/leaf | 24V DC | 1800 RPM | 230 × 90 × 110 mm |
Applications
-
Villas & courtyards
-
High-end residential communities
-
Banks, institutions, and security facilities
-
Commercial entrances & office buildings
Certifications & Compliance
-
CE, FCC, RoHS (on request)
-
ISO9001 Quality Management Certified
-
Patented design and gearbox technology
-
National High-Tech Enterprise Recognition
👉 With the SafeTS Overhead Series, you can provide customers with the ideal opener solution, balancing strength, safety, and silent performance across different gate sizes.
